Heavy haul sleeper for North-South line/Kingdom of Saudi Arabia.


The AR 06 heavy-haul sleeper was specially developed for the extreme requirements of the North South Railway Line in Saudi Arabia. The approximately 1,000 km long line is not only for freight but also for passenger trains. Extreme heat, high axle loads and sand drifts on the track are just a few of the special challenges. The design of this product combines the special customer specification with the high requirements of the AREMA Manual and is a durable and robust solution.

JENS KLEEBERG

CSO -  RAILONE

Features:

  • Design according to customer specification in conjunction with AREMA Manual
  • Designed for axle loads of up to 32.4 to



Advantages:

  • Compact design: Length 2.50 m
  • Flexibility: Adaptable to different rail fastening systems
  • Elasticity: sleepers can be produced with under sleeper pads
  • Safety: Can be equipped with an anti-derailment system


The AR 06 sleeper specifically has been designed for the specifications of the north-south. Due to the extensive experience of applications in North America, the relevant AREMA standards were used here. High axle loads, poorly maintained vehicles and tracks plus high, consistent tonnage on the line had to be managed for this product.

RHEDA 2000® High Speed ballastless track system for Haramain Line/Kingdom of Saudi Arabia.


The construction of the first high-speed line in a desert area began in 2011. It connects Mecca and Medina, the two most important holy cities of Islam. Millions of pilgrims and tourists are now able to cover the 444-kilometre distance in only about two hours. Technically challenging: a quarter of the route is threatened by siltation. The low maintenance requirements and the multiple testing of the RHEDA 2000® system were therefore decisive for the selection of the system. The opening was end of 2018.


Project details:

  • Temperatures in the desert region fluctuate between extremes of -10°C and +55°C
  • The operating speed will in future be up to 320 km/h
  • The rest of the line was equipped with ballast sleepers that can be flexibly adapted to the ground
  • RAILONE's scope of supply comprised approx. 210,000 RHEDA 2000® sleepers and approx. 500,000 ballast sleepers, manufactured in the concrete sleeper plant in Ha’il, Saudi Arabia
  • In addition, RAILONE supplies sleepers for the high-speed points, which are also built in RHEDA 2000®ballastless track, and supports the project team on site with additional engineering services relating to special issues regarding the planning, construction, and maintenance of ballastless track systems

RHEDA CITY for new Education City streetcar line / Doha


The Qatar Foundation commissioned the project in order to apply a new light rail system operating without overhead contact lines in the Education City, the university center in Doha, Qatar. Background and goal of the project is to simplify the transit within the Education City campus. The car running on the track bears a capacity of 233 people. For this extravagant project, RAILONE produced, supplied and installed sleepers of the proven RHEDA CITY system from the facility in Saudi Arabia. The ballastless track solution for urban transit was applied on the whole line with the length of 17 km. This system requires almost no maintenance, offers a high level of ride comfort, supports heavy loads and ensures great safety. All sleepers were transported from Ha’il, Kingdom of Saudi Arabia to Doha, Qatar via truck on a distance of more than 1,000 km.


  • Location: Doha Education City, Qatar
  • Solution supplied: RHEDA CITY ballastless track system
  • RAILONE scope of delivery: 16,959 sleepers produced, supplied and installed
  • Operational speed of the line: 100 km/h
  • Track length: 17 km
  • Project Started in October 2013 and ended in April 2015


RHEDA CITY as a covered track can be designed both with rail sheathing and with rubber granulate chamber filler elements. Due to the lateral stability inherent in the system, this system is also suitable as a design with continuous rail bedding. In principle, track covering is possible with all common road surfaces - asphalt, concrete (also as a precast element) or paving. The system structure is not changed in the variant with road covering. Usually, the roadway slab is concreted to just below the rail base, so that the desired rail recess is possible. In contrast, continuous rail bedding involves concreting down to the rail foot, which is, however, naturally supported softly on the roadway slab by an elastic sheathing.


Due to the system design, the components affected by wear - rail and track covering - are installed in such a way that they can be easily separated from the track slab. This means that these components can be replaced at the end of their service life or after complete wear, while essential parts of the track can remain in place. After about eight to twelve years, rail replacement is often necessary, which can be carried out together with renewal of the pavement. The result is a roadway that is practically as good as new.


Covered tracks can also be realized in conjunction with Vignol rails if suitable rail profiles are used. More common here, however, are systems with grooved rails, which have higher manufacturing tolerances. Due to low heights, in some cases there is not enough space for the track covering, which places very special requirements on the rail fastening. RAILONE has therefore developed the NV-1 system especially for covered tracks with grooved rails.
